16 GAUGE / 7 CONDUCTOR SEOOW / STOOW
ENTERTAINMENT LIGHTING CABLE

Kalas 16 GAUGE / 7 CONDUCTOR SEOOW ENTERTAINMENT LIGHTING CABLE

Construction

Conductor material: .010″ bare copper
Gauge: 16
# Conductors: 7
# of strands: 26
Operating Temperature: -50°C to 105°C
Meets Requirements: RoHs, REACH, UL 62 and CSA 22.2 No. 29-14

Insulation Singles;

  • PVC compound; 105°C
  • .123”+/-.003” diameter
  • .030” nominal wall
  • Color/Sequence: Green/Brown/Light Blue/Yellow/Black/White with 1 Purple Stripe/Red

Insulation Jacket;

  • TPE compound; 105°C
  • .563” +/- .010” diameter
  • .080” nominal wall
  • Matte black jacket

Print Legend

7/C 16 AWG ( 1.31mm² ) E31793 (UL) SEOOW 600V 105°C (WATER RESISTANT 60°C) VW-1 — 7/C 1.31mm² ( 16 AWG ) LL22035 CSA SEOOW 600V 105°C VW-1

Applications

Entertainment lighting.

Features

  • TPE jacket designed to withstand repetitive coiling

  • Paper separator allows for ease of stripping

  • Flame retardant to UL VW-1
  • Rated to 600 Volts
